Brand: Compatible with HP
Product Type: 768p eDP Screen compatible with Hp Compaq 847654 007
See also: 828163-001 847654-002 847654-003 NT156WHM-N32 LTN156AT39-H01 812702-001
Condition: New & Class 1 (ISO-9241)
Warranty: 2 years return to base
You are viewing a Hp Compaq 847654 007 Class I and fully compatible (with 828163-001, 847654-002, 847654-003, NT156WHM-N32, LTN156AT39-H01, 812702-001, and other models) LCD part. We have these screens with a GLOSS (Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1366X768 (or is known as HD resolution or 768p). This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. Hp Compaq 847654 007 screen replacement cost is just £59.94 plus shipping.
Hp Compaq 847654 007 15.6 installation guide (video). - Opens in external window
You need to replace the broken screen. Watch our video on How to replace a Hp Compaq 847654 007 LCD screen part.
You might need this screen replacement. Check with an external monitor. Here are the instructions to check the problem related to white screen on laptop.
