Asus Zenbook 14 (oled) Um3406h (2.8k) (oled) Replacement Screen Rear-view

40 Pins - 25mm wide connector

4.8 ★★★★★ 411 Google reviews
4.9 ★★★★★ 2,892 Trustpilot™ reviews

LCD Mounting Strips Stretch Release Tape

£4.99+VAT (What's this?) Stretch Adhesive Tape is a special LCD tape that can be removed easily (unlike double-sided tape), by pulling tabs at the end of the tape.

LCD Toolkit Toolkitimage

£8.33+VAT (What's this?) Spuder, Knife, Pry-tool, Tweezers & Screwdriver. Everything you need to make installation easier and safer.

ASUS ZENBOOK 14 OLED UM3406H 2.8K OLED Replacement Laptop Screen ( Not Touch )

4.8 ★★★★★ 411 Google reviews 4.9 ★★★★★ 2,892 Trustpilot™ reviews

SKU

2698935

Condition

NEW, Class 1 (ISO-9241)

Size

14.0"

Resolution

2880X1800 (2.8K)

Backlight

OLED

Touch Screen

Touch Glass

Not included

Finish

Color Shine™ / Glossy (Glare)

Connector

40 PIN EDP (bottom right)

Connector Pitch

0.5mm (Large)

Frame Rate

90hz Refresh

Frame Rate

120hz Refresh

Screen Bezel

Narrow Border/Narrow Bezel

Colours

High Gamut 100% sRGB

NTSC

72%

Alternative Technology Available
90HZ OLED

Have you got the right product?

This Zenbook computer has other screen types fitted. You must make sure you purchase the correct one which uses the same resolution and connector type.

Can I Upgrade My Screen?

Prices shown include UK VAT

Variations of Zenbook 14 OLED screens

Type

Backlight

Price

Trade

ASUS ZENBOOK 14 OLED UM3406H 14.0 WUXGA OLED

14.0"
-

No Stock

ASUS ZENBOOK 14 OLED UM3406H 2.8K OLED Screen (14" 2.8K)

This GLOSS 4690hz OLED 100%sRGB (high gamut) replacement screen is fully compatible with the ASUS ZENBOOK 14 OLED UM3406H 14" 2.8K OLED laptop that has a 2880X1800 display resolution. This product is not for touchscreen devices, this raw OLED panel does not include any touchscreen parts.

For displays with a 40 pin EDP 0.5mm pitch connector. Pick up this brand new latest available direct manufacturer original OLED panel for just £235.14, with fast UK and EU shipping and a free extended 2-year warranty.

Warning! Your device takes different screen types that are not interchangeable, you must choose the correct type.

Part Compatibility With (ATNA40CU09-0, and other models)

Should you buy this product?

If you have carefully checked that the specifications on this page match your laptop screen model, you are good to go. If you are still unsure, we advise removing your current screen and ordering by screen model number. If your old Zenbook 14 OLED screen is cracked, showing lines, flickering, completely black or white, it cannot be economically repaired and must be replaced with this compatible replacement screen.
