Brand: Compatible with AUO
Product Type: 768p eDP Screen compatible with B156xtn07.1 HW3A
See also: 5D10H52713 IDEAPAD 320-15IKB
Condition: New & Class 1 (ISO-9241)
Warranty: 2 years return to base
You are viewing a Auo B156xtn07.1 H/W:3A Class I and fully compatible (with 5D10H52713, 320-15IKB, and other models) LCD part. We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1366X768 (or is known as HD resolution or 768p). This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, which can be found at the bottom right side of the screen - on the back of the LCD. Auo B156xtn07.1 H/W:3A screen replacement cost is just £46.79 plus shipping.
Au Optronics Auo B156xtn07.1 Hw3a 15.6 installation guide (video). - Opens in external window
You need to replace the broken screen. Watch our video on How to replace a Auo B156xtn07.1 H/W:3A LCD screen part.
You might need this screen replacement. Check with an external monitor. Here are the instructions to check the problem related to white screen on laptop.
