20mm wide connector

HP 15S DY3000 Series Full-HD Replacement 1920x1080 Laptop Screen
( Without Touch Glass )

NEW, Class 1 (ISO-9241)
1920X1080 (FHD) 1080p
Touch Screen
Touch Glass
Not included
Matte (Anti-Glare)
30 PIN EDP (bottom right)
Connector Pitch
0.5mm (Large)
Display Mode
Screen Bezel
HP MicroEdge™ Screen

Alternative Finish Available:
Glossy / Glare
Alternative Technology Available:
60HZ TN 72% NTSC / 100% sRGB
ⓘ  Next UK Special Delivery day after the bank holiday, on Wednesday the 29th May. Tracked 48™ packages arrive Thursday 30th May (not guaranteed).
ⓘ  Add 10 or more to cart to buy these for £33.22 + VAT [ Wholesale Information ]

LCD Mounting Strips

Stretch Release Tape£4.99+VAT

ⓘ What is Stretch Release Tape?

Have you got the right product?

The currently selected product on this page is a 15.6" 1920X1080 (FULL HD) with a LED backlight and a 30 Pin signal, bottom right connector, with a 0.5mm connector pitch.

This HP computer has other screen types fitted. You must make sure you purchase the correct one which uses the same resolution and connector type.

Can I Upgrade My Screen?    How do I Order By Screen Model?

Prices shown include UK VAT

 Variations of HP 15S DYxxxxxx models screens

Matte. Bottom right connector 40 pins (0.5mm) Touch




Gloss. Bottom right connector 40 pins (0.4mm) Touch


No Stock


Matte. Bottom right connector 30 pins (0.5mm)




    Available to buy online
HP 15S DYxxxxxx models replacement laptop LCD screen
Hp Notebook Pc 15s Dy3000 Series 15.6 Full Hd Laptop Screen No DIGITIZER
30 PIN / 20mm

Class I Display for HP laptops
This is a replacement screen for the Hp Notebook Pc 15s Dy3000 (FHD) computer. Class I and fully compatible LCD display part.

HP 15S DYxxxxxx models LCD specifications.
We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920X1080 (or is known as FULL HD resolution or 1080p).

Technical data for the HP 15S DYxxxxxx models LCD.
This screen's backlight is powered by LED backlight technology. The data connector on this screen has 30 pins and is an eDP displayport, with a 0.5mm pitch, with a 302PL Pin Configuration, which can be found at the bottom right side of the screen - on the back of the LCD. This is a genuine IPS (AAS/ADS/AHVA or FFS/UWVA/PLS) screen offering ultra wide viewing angles.

100% Compatible part.
For the Hp Compaq Notebook Pc 15s Dy3000 (FHD). This display will replace many screen makes and models, including (but not limited to), the following part codes: L51997-001   L51998-001

Not Touchscreen. Raw LCD panel only.
HP 15S DYxxxxxx models screens can sometimes come touch screen enabled, this product is a non-touchscreen model. We are supplying the raw LCD panel only without any accompanying front touch glass overlay (digitizer). If your laptop has a screen and a glass covering providing touch screen features you will need the raw LCD and the digitizer glass together. Professionals can separate the old digitizer with a heat-gun (if not damaged), and fit it to the new display. If your laptop is not a touchscreen model, this is the correct product for you. Find out more about this.

Cost of HP screen.
Hp Compaq Notebook Pc 15s Dy3000 (FHD) screen replacement cost is just £46.74 plus shipping.

We give an industry leading 2 year warranty on all our high quality HP replacement laptop screens. Terms and conditions apply.

Fast Delivery
UK and Europe only. View Shipping Costs.

Certified Screen Replacement5 Star Rated Icon
Certified Screen Replacement5 Star Rated Icon

Hp 15s Dy3000 Series Full-hd Replacement Screen Buyer's Guide guarantee you a working Hp Notebook Pc 15s Dy3000 (FHD) screen replacement, or your money back. With our 18 years of trading experience, we can warrant that claim with real expertise. If you research our company, you will encounter our impressive accumulation of fantastic reviews on sites like Trustpilot and Google.

Touch Screen Models
Touch screen computers have two parts to the viewable display. They have a screen, like any computer and in addition they have another layer over the top of the screen that works like a mouse. That 2nd part is called a touch glass digitizer, and we aren't supplying that, we're selling just the LCD screen. In some cases you can re-use the old digitizer, unless of course it is damaged. If your old digitiser is damaged, this product is not for you. If your computer is not a touch screen model, you can go ahead and use this product with no problems. More about this...

Is the Hp Compaq Notebook Pc 15s Dy3000 Series 15.6 Full Hd Laptop Screen (non Touchscreen), the correct product for you?
HP are notorious for fitting different types of screen to the Hp Notebook Pc 15s Dy3000 (FHD) machine, and as such we ask you to please check the specifications of this screen match your original. To be 100% sure, it's best to remove your old screen first, and make sure it looks similar to the photograph we provide, and that the resolution, connector type and connector position match as well. Other screens available...

Changing screen resolution.
If you are looking to upgrade (or downgrade) the resolution, say from HD to FULL HD, you need to check a couple of things first before you try the upgrade. Check that the upgrade screen you want to purchase has the same mountings, connector type and connector position, by comparing the photographs on each product page and the connector specifications in the description. Next you'll need to make sure you have a screen cable fitted that is capable of the resolution you wish to change to. As this is tricky we advise against upgrading unless you know what you are doing. More about this...

Glass finish
HP Screens can be manufactured in MATTE or GLOSSY finish. MATTE is better for outdoor use and GLOSS is better for indoor use. GLOSS screens will display brighter and richer colours, and MATTE screens will look duller, but are less reflective. We try where possible to offer both options, if we have both options, we will offer them in the product description. More about this...

Screen size measurement
We always list the size of the screen to help you determine which product is right for you. Screen sizes are measured diagonally, from corner to corner, of the visible display area only. The measurement does not include any frame (or bezel), just the area that lights up and is part of the display area. More info about this...

18 years' experience
We have the largest screen replacement database on the Internet. In addition to this, you have peace of mind that we have many years of trading, during which time we have accumulated a wealth of knowledge, which enables us to provide the right screens, first time. The long time we have been established has also enabled us to build sterling relationships with top manufacturers like AUOChiMei InnoluxSamsungHannstarToshibaLG DisplaySharpBOEHydis Hundai,  and others.

Better quality screens
We insist on higher grade Class I panels, (note that there is no such thing as a Grade A screen). We pay a little more to ensure our products impress and please every time, and give a long working lifetime. With more than a decade of experience our team will ensure your high quality replacement screen is as good - or better than your original display, and that the whole process from purchase, through the delivery and to installation, is seamless. And this promise is endorsed by our customers.

Get more help

Do I need a new HP 15S DYxxxxxx models laptop screen?

Solution: You need to replace the broken screen. Watch our video on How to replace any laptop screen.

Solution: You might need to buy this screen replacement product. Check your video cable behind the screen. Here are instructions to check on laptop screen flickering.

Solution: You may need to replace the screen. Check with an external monitor. Here are the instructions to check vertical lines on laptop screen. You can follow these guidelines for horizontal lines on laptop screen also.

Solution: You might need this screen replacement. Check with an external monitor. Here are the instructions to check with an external monitor.

Solution: You might need this screen replacement. Check with an external monitor. Here are the instructions to check the problem related to white screen on laptop.

More solutions can be found by checking our Laptop Screen Troubleshooter

Universal Laptop Screen Installation Video

131,791 views • 23 May 2021  |  Slow Playback? Standard Quality

Recently viewed products


    This screen is only for devices with 15.6" displays @ 1920X1080 (FULL HD) resolution with a LED backlight and a 30 Pin signal, bottom right connector, with a 0.5mm connector pitch.

    This product is not for touch screen devices. [ Info ⓘ ]

    There are different screen type choices for your device on this page. You must choose the correct type. If you are unsure which type to choose, we recommend removing your old screen and searching for the screen model number instead.
