LENOVO IDEAPAD Y510P FULL HD REPLACEMENT 1920X1080 LAPTOP SCREEN

View larger Image

★★★★★  0 Customer Reviews. Leave a review for this product


OUT OF STOCK / UNAVAILABLE

This item (ibm lenovo ideapad y510p laptop screen part), is currently unavailable and we are unable to locate a supply of this product at the moment. For more information, see the product description below.


IBM Lenovo Ideapad Y series replacement laptop LCD screen

Brand: Compatible with IBM
SKU: 986432
Product Type: 1080p Full-HD LVDS Laptop Screen
See also: LP156WF1 TLC2   B156HW02 V.1   compat issues sometimes try L9?
Condition: New & Class 1 (ISO-9241) ?
Warranty: 2 years return to base

Ibm Lenovo Ideapad Y510p 15.6 Full Hd Screen Replacement

You are viewing a Ibm Lenovo Ideapad Y510P Class I and fully compatible (with LP156WF1, B156HW02, and other models) LCD part. We can supply this LCD with a MATTE (Anti-Glare) finish. Please check that your original screen has a glass area of 15.6" inches diagonally (not including the frame) and has a maximum resolution of 1920x1080 (or is known as FULL HD resolution or 1080p). This screen's backlight is powered by LED backlight technology. The signal connector on this LCD is 40 pin and is a LVDS displayport, at the bottom left side of the screen, when looking from the back.

How to install:

Can't see the video above?

Ibm Lenovo Ideapad Y510p 15.6 Full Hd Screen Replacement installation guide (video). - Opens in external window

Do I need a new IBM Lenovo Ideapad Y series laptop screen?



Ibm Lenovo Ideapad Y510P laptop screen flickering

Ideapad Y510P Screen Flickering

You might need to buy this screen replacement product. Check your video cable behind the screen. Here are instructions to check on laptop screen flickering.

Ibm Lenovo Ideapad Y510P laptop screen with lines

Lines on Lenovo Screen

You may need to replace the screen. Check with an external monitor. Here are the instructions to check vertical lines on laptop screen. You can follow these guidelines for horizontal lines on laptop screen also.

Ibm Lenovo Ideapad Y510P laptop screen completely black

IBM Lenovo Black Screen

You might need this screen replacement. Check with an external monitor. Here are the instructions to check with an external monitor.

Ibm Lenovo Ideapad Y510P blue screen

Blue Screen on IBM Lenovo Laptop

You might not need to replace the screen. Here are some resources for you to rectify the blue screen on laptop.

Ibm Lenovo Ideapad Y510P laptop screen completely white, Ibm Lenovo Ideapad Y510P laptop screen whiteout

White Screen on IBM Lenovo Laptop

You might need this screen replacement. Check with an external monitor. Here are the instructions to check the problem related to white screen on laptop.
