Ibm Lenovo Legion 5 15imh05h (fhd) (240hz) Replacement Screen Rear-view

40 Pins - 25mm wide connector

Lenovo LEGION 5 15IMH05H Series Full-HD 240hz Replacement Laptop Screen

SKU

1588105

Condition

NEW, Class 1 (ISO-9241)

Size

15.6"

Resolution

1920X1080 (FHD) 1080p

Backlight

LED

Finish

Matte (Anti-Glare)

Connector

40 PIN EDP (bottom right)

Connector Pitch

0.5mm (Large)

Frame Rate

240hz Refresh

Panel Type

IGZO

LCD Model

Part code sent varies

Screen Gamut

Varies

NITs & cd/m2

Varies

Screen Bezel

Narrow Border/Narrow Bezel

Have you got the right product?

This Legion computer has other screen types fitted. You must make sure you purchase the correct one which uses the same resolution and connector type.

Can I Upgrade My Screen?

Prices shown include UK VAT

Variations of Legion 5 15 Inch models screens

Type

Backlight

Price

Trade

LENOVO LEGION 5 15IMH05H SERIES 15.6 FULL HD 144HZ
Matte. Bottom right connector 40 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

£55.14

£51.27

LENOVO LEGION 5 15IMH05H SERIES 15.6 FULL HD 60HZ
Matte. Bottom right connector 30 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

£53.94

£50.16

LENOVO LEGION 5 15IMH05H SERIES 15.6 FULL HD 120HZ
Matte. Bottom right connector 40 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

£51.54

£47.92

LENOVO LEGION 5 15IMH05H 81Y6 SERIES 15.6 FULL HD 144HZ
Matte. Bottom right connector 40 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

£55.14

£51.27

LENOVO LEGION 5 15IMH05H 81Y6 SERIES 15.6 FULL HD 240HZ
Matte. Bottom right connector 40 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

No Stock

LENOVO LEGION 5 15IMH05H 81Y6 SERIES 15.6 FULL HD 60HZ
Matte. Bottom right connector 30 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

£53.94

£50.16

LENOVO LEGION 5 15IMH05H 81Y6 SERIES 15.6 FULL HD 120HZ
Matte. Bottom right connector 40 pins (0.5mm)

15.6"
FULL-HD
1920X1080

LED

£51.54

£47.92

LENOVO LEGION 5 15IMH05H SERIES FULL HD 240HZ Screen (15.6" FHD)

About this product

This Matte 240hz LED replacement LCD screen is fully compatible with the LENOVO LEGION 5 15IMH05H SERIES 15.6" FULL HD 240HZ laptop that has a 1920X1080 display resolution.

For displays with a 40 pin EDP 0.5mm pitch connector. Pick up this brand new latest available panel for just a fraction of the cost of a new device, with fast UK and EU shipping and a free extended 2-year warranty.

Premium 240Hz Refresh Rate

With a rapid 240Hz refresh rate, this ultra-fast gaming screen is ideal for high-performance systems where smooth motion, quick response and competitive play matter. Upgrading the refresh rate of your current display is possible only if the new display has the same size, layout, resolution and connector as your original, and your laptop supports 240hz displays.

Warning! Your device takes different screen types that are not interchangeable, you must choose the correct type.

Compatible Parts

This product is compatible with (LP156WFG-SPX1, 5D10X18110, B156HAN10.2-HW0A, 5D10X18113, and other panel models)

Should you buy this product?

If you have carefully checked that the specifications on this page match your laptop screen model, you are good to go. If you are still unsure, we advise removing your current screen and ordering by screen model number. If your old Legion 5 15 Inch models screen is cracked, showing lines, flickering, completely black or white, it cannot be economically repaired and must be replaced with this compatible replacement screen.
