HP EliteBook 8560p Screen Replacement

Replacing a HP EliteBook 8560p screen

A broken HP EliteBook screen need not be a cause for concern. In fact, laptop screen replacement requires very little technical expertise. We receive hundreds of testimonials from satisfied customers who are genuinely surprised at how easy the entire process is.

How to replace a HP EliteBook 8560p screen

Step one

Unplug your laptop and remove the battery. You should also pause to make sure that you have disconnected all external devices, (eg. speakers and/or memory sticks.) Then, use your fingers or a flat edged implement, ( a debit card or razor,) to prise the aesthetic covers off of the bottom corners of the front bezel. Once you've removed these covers, remove the screws hidden underneath and, set them aside safely.

Step two

Firmly, (but gently,) prise the front bezel away from the rest of the screen casing. Work your way around each side of the front bezel, easing it away from the rest of the screen casing. On removing the front beze,l you should see the broken HP EliteBook 8560p screen being held in place by six further screws, (two in the top corners and four at the bottom.) Remove all of these screws and, set them aside safely.

Step three

Take hold of the top of the screen and, gently pull it towards you. Lay the screen face down on the laptopkeyboard. On the back of the screen, you should see a thick cable attached to a gold connector. Disconnect this cable, (peeling back any stips of adhesive holding it in place, if necessary.)

Step four

Remove the HP EliteBook 8560p screen from your laptop. To fit your newly bought replacement, simply complete the inturctions, (as provided above,) in reverse.

Replacement HP EliteBook 8560p screens



*Disclaimer: As with any repair you choose to undertake, Laptop-LCD-Screen.co.uk cannot be held responsible for any damage caused to your device during the replacement/repair process. If you feel anxious or unsure about completing this repair yourself, it is best to err on the side of caution.
